Audio E 05 Visual Alarm For Mining Machinery

AUDIO

Duel Pizo-Buzzer, while reversing, delivering Alarm of 110 dB (measured at a distance of 1.2 meter distance). Two buzzer's are arranged in such a way that if any fault occurs in one buzzer, other will work without any interface.

VISUAL

Bright focus type Red LED (24 nos. of 5 mm size) blinks continuously while Reversing, emitting uniform light of 300 Lux. brightness.

VOLTAGE

Operates ideally on 24 Volt D.C. and 12 Volt D.C.

CURRENT

The maximum Current consumption is 15 Amp

PROTECTION

The electronic circuits and buzzers are totally sealed by epoxy resin, so that nothing can enter in it. Our Audio Visual Alarm is 100% Water Proof and tested on IP67 rated. It even works after totally immersed in water. It does not have free space to accumulate ingress dust water into its enclose.

TIMER

To reduce the noise pollution and also to protect the smart alarm, 2.5 minutes timer is provided which shut off alarm automatically (as per DGMS requirements).

DIMENSION

Length-154 mm, Height-82 mm and Depth-75 mm

WEIGHT

1.2 kgs. approx.

ENCLOSURE

Aluminum Body and M.S. sheet
